7colors 360degreeuniversal cameraFront|Side|Rear46% off sales | Car Video Parking Sensor Reverse Backup Radar Assist Auto parking Digital Display radar For DVD TFT15% off sales | 4cameras control box with TF card four video record four way DVR25% off sales |
If you need ,you have to leave message to us ,only can be send from China ,Can\'t select for Russian and US shipment) |
Common problems and solutions(Kindly answer your questions:) (1) Can this camera install onrearview mirrorrecorder? NO, it can\'t ,Usually it can connect TFT monitor, mirror monitor,RCA DVD ,but can\'tsupport any Driver recorder. (2)about the video line, it is AV or AVIN(2.5mm) for portable? AV is default,if you need AVIN ,please leave message follow your order,(only support Shipment from China ) (3).Why the image occurred jitter, splash screen, interference,unstable, Black and white color when you are reversing? 1)The image becomes black and white color just because you buy a wrong TV system. This camera built in NTSC system as default, if your monitor is PAL system, it will be showed jitter ,Black and white color. Solution: a. Please set up the GPS TV system as automatic firstly when using, then see whether it still can set the system. Because there are many monitor with 2 system in market, it can set. But some old-type GPS can\'t set. So please choose the right system to fit thecamera. b. Please must check the right cable connection installation. c. If above solutions still can\'t deal, please ask your local professional car staff for help. 2)The image occurred jitter,splash screen, unstable just becausethe voltageis lower than we suggest. Solution: Different place and using-situation will occurred some of the car output voltage is different. Car reversing is not powered by DC, it will add a Pulse signalto disturb , so it will unstable .So we suggest you need check the voltage whether as 12V,or please add a delay to use. (4)our car have video and power cable,Can you use it when I buy this camera? Yes, it can, it support RCA plug. But we suggest you don\'t use youself cable, because the line may beaging and defined different . 7.How to install? a. For universal camera, it installs through 2 screws and backrestor .it can fix near the location oflicense plate light. b. For dedicated camera, it installs in license plate lightdirectly. We suggest you install the camera in professional car modification and beauty shop All chips description below below CCD camera\'s image shown CCD camera is high clear, better quality than the Colorful CMOS andCMD
Image Sensors | 1/3"forCCDSony color |
TV System | NTSC/PAL(NTSC as default,If you want Pal system, please note it) |
Effective Pixels | 728X582/728x512 |
Sensing Area (mm) | 3.3 x 2.6 |
Resolution (TV Lines) | 600 |
Minimum illumination | <0.1 Lux / F1.2 |
Horizontal Sync.Frequency | 15.625 KHZ |
Vertical Sync.Frequency | 50 HZ |
Video Output | 1.0Vp-P75 Ohm |
AGC | Auto |
BLC | Auto |
Night Vision | Yes |
IP Rating | ip67~68 |
S/N ratio | Better than 48dB |
Lens | F=1.8 |
Lens Angle (Deg.) | wide angle 170 (Diagonal angle) |
Current Consumption (mA) | 85~115 |
Power Supply (DC V) | 12V |
Operating Temperature (Deg.C) | -20~ 75(RH95% Max.) |
Storage Temperatur(Deg.C) | -40~ 85(RH95% Max.) |
For wire camera (this link only wire) 1 x car Camera 1x 6m video cable 1x power supply cable 1X user manual | For wireless camera: 1x car camera 1x Transmitter 1x receiver 1x user manual |
It is seldom, but if you can not accept any delay, please choose fast shipping or do not bid the item. Fast shippingExpress Service ( EMS,DHL,USPS ) is available, Contact us If you have any questions please feel free to contact us . We will respond within 1 business day or less.
It \'s our honor to provide excellent service for you, thank you! Return policy What Happens If I have a Problem?
If you have a faulty or damaged item or for any reason receive what appears to be incorrect goods please contact us by chatting massage or email ,and explain your problem. We will respond within 1 full working day. Could I get my money back ?
Sure. if you want to return the item for above reason or any other seasons within 14 days after item received, we will offer a full refund to you once the item is sent back with original package. How about the return shipping fee ?
Please kindly know that the buyer will be responsible for the return shipping fee, thanks for your kindly understanding.Feedback:
Please leave us positive feedback and 5 stars in all detailed ratings if item received in good condition;
For Buyers that is not satisfied with your shopping Experience, you can always contact us first before you leave feedback;every problem could be worked out via good communication between both sides.Thank You So Much For Shopping in our store.
